Linear shower drains, like many other elements in the home, are a basic feature that has remained largely unchanged over the years. Depending on how you shower, they are usually in the middle, or if your shower is also a bathtub, at one end. But that's not your only option. Linear shower drains, sometimes called infinite shower drains, are virtually invisible.
Here is the content list:
The function of a linear shower drain system
Performance of the product's structure
Experience multiplied
An efficient linear shower drain system should try to be as fast as possible to collect and drain, and separate the collection and delivery. Drainage in zones, reasonable allocation of the catchment area, minimizing the runoff distance and retention time of surface rainwater, and achieving the purpose of the fast collection. While linear shower drain system is mainly responsible for collecting surface water, water transmission mainly relies on pipes, and reasonable arrangement of outlet and transmission pipes to ensure smooth drainage.
In addition, the linear shower drain system is different from other traditional drainage structures in that it has its gluing groove structure. So, all the components can be connected and then filled with a special waterproofing tightening agent in the gluing groove, which ensures that the linear shower drainage connection has a tight waterproof performance.
The linear shower drain structure is composed of five major parts from top to bottom: linear grille panel, filtering parts, anti-odor parts, bottom groove, and drainage outlet.
Linear grille panel: linear long strip-shaped, the market is mostly made of stainless steel. Drainage over a large area of water.
Filter: installed in the linear shower drain bottom groove, can effectively block hair and other debris to prevent sewer clogging, generally divided into the concave filter and convex filter.
Anti-odor parts: connected with the filtering parts, anti-odor parts are the most important parts of the floor drain, to prevent insects, odor, and overflow effects. Generally divided into V-type silicone deodorant parts or T-type metal deodorant parts.
Bottom groove:linear shower drainssystem drainage temporary storage place, water first through the bottom groove, after filtering discharge. Generally, there is a water guideline on the bottom tank.
Drain: The part of the floor drain that drains to the sewer, the caliber needs to be slightly smaller than the sewer orifice.
Safety:
Linear shower drain overrides the height difference design of traditional floor drains in the drainage area and can be installed horizontally and firmly on the ground, which helps children, the elderly, and people with limited mobility to pass safely.
Convenience:
The linear shower drain's long strip design requires only one or two sides of the tile to be tilted during installation, making it easy to tile, shortening man-hours, and saving labor costs.
Aesthetics:
Linear shower drains can be tailored in length and shape to meet the needs of different environments. It also effectively improves the flatness of the floor and increases the practical value of the space.
The innovative character of our product range has grown over generations so DIKALAN is often a trendsetter in the field of hygiene. We are the inventor and developer of the easy linear drain shower system, thus sparking the craze for free obstructions in private bathrooms.
It is reported that the Bei'anhe Depot on the first section of Line 16 has the largest construction scale in the city, covering an area of 31.55 hectares and a total construction area of 313,100 square meters. The comprehensive utilization of the depot is based on the principle of "comprehensive development guided by public transportation". Through its construction, a transportation network system including rail transit, buses, tourist buses, bicycles and walking will be formed to facilitate citizens' travel.
The humanization of Line 16 is first reflected in the setting of the bathroom. There are 7 toilet seats in female toilets, which meets the requirement of less than 1:2 for men and women, and far exceeds the number of toilet seats for women in general subways. This design can effectively alleviate the difficulty of toileting for female passengers during peak periods. In addition, the barrier-free toilet is equipped with a changing table to meet the needs of mothers and babies; the customer service center has a "Z"-shaped countertop with a semi-circular groove, so that passengers can conveniently place personal belongings when buying tickets.
At the same time, a total of 2,000 cameras were installed in the first section of Line 16, which is the first line in Beijing to adopt a high-definition IP camera video surveillance system. The system can locate, identify and track the target in the dynamic scene through real-time analysis of the surveillance video image, and analyze and judge the target behavior, so that it can respond in time when an abnormal situation occurs, and achieve early detection and active prevention , To help security personnel effectively avoid or efficiently handle emergencies.
It is reported that the Bei'anhe Depot on the first section of Line 16 has the largest construction scale in the city, covering an area of 31.55 hectares and a total construction area of 313,100 square meters. The comprehensive utilization of the depot is based on the principle of "comprehensive development guided by public transportation". Through its construction, a transportation network system including rail transit, buses, tourist buses, bicycles and walking will be formed to facilitate citizens' travel.
The humanization of Line 16 is first reflected in the setting of the bathroom. There are 7 toilet seats in female toilets, which meets the requirement of less than 1:2 for men and women, and far exceeds the number of toilet seats for women in general subways. This design can effectively alleviate the difficulty of toileting for female passengers during peak periods. In addition, the barrier-free toilet is equipped with a changing table to meet the needs of mothers and babies; the customer service center has a "Z"-shaped countertop with a semi-circular groove, so that passengers can conveniently place personal belongings when buying tickets.
At the same time, a total of 2,000 cameras were installed in the first section of Line 16, which is the first line in Beijing to adopt a high-definition IP camera video surveillance system. The system can locate, identify and track the target in the dynamic scene through real-time analysis of the surveillance video image, and analyze and judge the target behavior, so that it can respond in time when an abnormal situation occurs, and achieve early detection and active prevention , To help security personnel effectively avoid or efficiently handle emergencies.
We can't live our daily lives without a shower, and the shower inside the home sometimes encounters the problem of clogged linear shower drains. If the shower drain is clogged, daily bathing will be very inconvenient, once the clog is found to be cleaned up as soon as possible. Here are a few tips to share about clogged linear shower drain in the shower room, so you can easily solve it.
Here is the content list:
Clogging caused by hair
Clogs caused by grease and grime
Clogging caused by hard objects
Clogging caused by renovation
After using a linear shower drain for a while, hair in the bath will hang on the wall of the pipe and accumulate more, which can cause a clog. Usually, hair can cause clogged toilet floor drains, clogged basins, clogged bathtubs, and clogged showers. Therefore, it is important to cover floor drain covers and other protective devices for linear shower drains during normal use. If there is hair, pick it up and throw it in the trash. How do I deal with a clogged linear shower drain with a lot of hair in the shower? This clog is easy to fix. You can use a hand unblocked to unblock the water or, if it is very serious, you must use a pipe unblocked.
Clogged linear shower drains caused by grease are usually found in kitchens, and such clogs are usually caused by scaling on the inside of the pipes. If the blockage is severe, you can use an unclogged to unblock the drainage. If it is serious, the simple unclogging method cannot be solved, there will be just unclogged again, completely solve the problem can only be used to use a high-pressure water tanker to clean the inner wall of the pipe or a new linear shower drain. Relatively speaking, it is more economical to use a high-pressure cleaning truck to unclog.
It is also very common for hard objects to fall into the linear shower drain to clog the drain. Some people do not cover the floor drain cover well so some small things fall into the water pipe and cause clogging, how to solve it? If it is visible to the naked eye, you must use a hook-up tool to remove the foreign object from the linear shower drain or try using a vacuum cleaner. If it is not visible, then you can use a household vacuum cleaner to try and sometimes produce unexpected results. If it is still not there, then a professional dredging tool must be used, and this is best solved by a professional linear shower drain age company.
This is one of the more common clogging problems in house renovations, and we have encountered many cases of clogged linear shower drains caused by inadvertent renovations. This is not an accident. That's why it is important to make good protective measures before renovation. This linear shower drainage blockage is usually caused by cement blocks, tile fragments, sediment, paint, woven bags, etc. If it is a soft object such as a woven bag, then you can use a dredge to unblock the linear shower drain directly. If it is hard objects such as cement crumbs, a professional linear shower drain age company is needed to unclog them.
DIKALAN has a strong technical force, sophisticated processing equipment, advanced production technology, and high-precision detection methods. If there are shower products needed, we are very much looking forward to working with you!
Linear shower drains products have many characteristics, such as pressure resistance, bending resistance, freeze-thaw resistance, strength, corrosion resistance, acid and alkali resistance, long life, smooth surface, no infiltration, maintenance-free, lightweight, easy to install, etc. Since it is popular because of so many features, the following is a list of steps and methods for installing linear shower drain.
Here is the content list:
Determine the pit
Test data ready for paving
Check again to reduce the error
Step 1: Drainage trench measurement and alignment:
Mark the direction of the finished linear shower drains with white ash on the foundation ready for excavation to ensure the accuracy of the pit for the drainage trench.
Step 2: Excavation of the finished linear drain trench;
Depending on the size of the drainage trench selected for the linear shower draintrench plan, a small excavator can be used to excavate the finished linear drainage trench with a width of ≤U100-U150; a large excavator can be used to excavate the finished linear drainage trench with a width of ≥U250-U350.
Step 3: Excavation of the finished linear drain trench;
Need to measure the slope of the linear shower drains, after calibration to start pouring the drainage ditch sub-base; after pouring the drainage ditch sub-base re-examine the elevation, slope, and data to meet the standard before the next step of construction.
Step 1: Pull the line to position the finished linear drain;
Place a small section of the finished gutter along the bottom base of thelinear shower drain, before installation to observe whether the reserved pouring space between the bottom base of the drain and both sides of the linear shower drain is sufficient. Test the data to meet the standard pull line positioning to start the formal paving.
Step 2: Measure the level of the linear gutter;
Workers install linear shower drain gutter docking gutter groove for sealing the seam gluing. It is easy to cause the deviation of the two ends of the finished linear gutter not at a level, and you need to master workers with a rubber hammer knocking flat while using a level measuring instrument to check the level error, such as height difference should not exceed 1-2mm.
Step 3: Pouring the concrete base on both sides of the drain;
Both sides of the finished drain in the base of the linear shower drain pavement should be fixed, the joints of the drain pile mortar to keep the finished linear drain not deformed, thelinear shower drain unblocked at the mortar solidification began to pour concrete on both sides of the finished linear drain.
Step 1: Laying the finished linear gutter cover;
With the linear shower drain base foundation and concrete foundation on both sides, half of the construction of the linear drain is completed. Again, the level of the finished drain is checked with a level measuring instrument to be within the error range and the linear shower drain cover is started to be paved.
Step 2: Spreading mortar on the linear shower drain cover
The mortar spread on the linear shower drain gutter cover is for the stone or turn to do the foundation bedding, according to the thickness of the selected stone. The thickness of the selectedlinear shower drain gutter cover is also different, according to the load strength reference EN1433 standard requirements to choose the different load-bearing grade of the gutter cover.
Step 3: Stone paving
The stone pavement is generally 3-5mm higher than the linear shower drains gutter downspout, and the stone is glued to the downspout to ensure that the water flows quickly, and is discharged from the gutter to the nearest public domestic water network.
Wenzhou Decalan Sanitary Ware Co., Ltd. is a domestic professional manufacturer of sanitary ware. The company has a strong technical force, sophisticated processing equipment, advanced production technology, and high-precision detection methods.
Recently, the news that "5A-level tourist attractions in the country must be equipped with a'third toilet'" has attracted the attention of many citizens. What does this special facility look like, independent of men's and women's toilets? These two days, the reporter visited Some streets, shopping malls and parks in our city have indeed found some similar facilities. Have you ever seen and used these toilets?
Convenience: This kind of bathroom makes it no longer embarrassing for parents to take their children to the bathroom
Yesterday, in a large shopping mall on Kaixuan Road, the citizen Ms. Mao took her son into a special bathroom: its door did not have the common words "male" or "female", instead it was replaced by a striking parent-child icon ( As shown in the picture), when entering the bathroom, there is an icon with the words "Mommy & Baby" on the wall on the left hand side, and the icon "Daddy & Baby" on the right hand side.
Ms. Mao took the child to turn left and solved the "convenience" problem in one of the cubicles. It was not the first time that she brought her son to this bathroom. In Ms. Wang's view, such partitions provide a lot of convenience for fathers and mothers who take their children alone, "and there are also children's toilets, which are simply too practical."
From a functional point of view, the toilet that Ms. Wang uses with her son is the "third toilet."
Question: These toilets have special functions, but they have been left out
The reporter visited and found that many public toilets have set up facilities similar to the "third toilet" around us. In most cases, they are shown as "barrier-free facilities": an icon with a wheelchair is posted at the door. Safety handrails, railings, etc. are installed beside toilets and sinks.
In a public toilet on Dingding North Road, the reporter found a "third toilet" with relatively more facilities, which not only has common barrier-free facilities, but also a crib that can change diapers for babies. However, the reporter was in the public toilet. After observing for a long time, I didn't see anyone using this bathroom. Asked why, many citizens said that they thought this was a toilet for disabled people only.
According to the relevant person in charge of the Municipal Environmental Sanitation Department, there are 657 urban public toilets in the urban area of the city. Among them, the urban public toilets located near some scenic spots have the dual functions of urban public toilets and tourist public toilets, so barrier-free toilets or maternity and infant toilets with the function of “third toilet” were installed during construction. However, due to the recognition of the citizens Degree and management reasons, some of them did not fully perform their original functions.
Suggestion: I hope it can be extended to more places in the future
During the interview, many citizens put forward their views on the novelty of the "third bathroom".
Mr. Zhou, who lives in Jianxi District, believes that the "third bathroom" should not only have a scenic spot, but it should also be promoted to the whole society; college student Xiao Wu suggested that the "third bathroom" can be added with some detailed instructions at the door to let everyone understand it. The specific function is because many people may be embarrassed when they enter the door suddenly; Ms. Song, who has retired, feels that the hospital should also set up some separate "third toilets" so that when she goes to the hospital to take care of her spouse and children, she will be embarrassed. Don't worry about helping him to the toilet anymore.
The reporter learned from the Municipal Environmental Sanitation Department that although the "third toilet" is not compulsorily included in the urban public toilet construction standards, the city encourages public places with conditions to install more convenient public toilet facilities. In the future, as the urban infrastructure continues to improve , Around us, there may be more fully functional "third toilets".
Source: Luoyang Evening News (Reporter Wisdom Text/Picture)
Related Links
"Third toilet", also known as family toilet in the world, refers to a toilet specially set up for people with behavioral disabilities or relatives (especially the opposite sex) who cannot take care of themselves. It is used to solve the inconvenience of toileting for some special objects. Problems, such as daughters assisting old fathers, sons assisting old mothers, mothers assisting little boys, fathers assisting little girls, etc.
Recently, the news that "5A-level tourist attractions in the country must be equipped with a'third toilet'" has attracted the attention of many citizens. What does this special facility look like, independent of men's and women's toilets? These two days, the reporter visited Some streets, shopping malls and parks in our city have indeed found some similar facilities. Have you ever seen and used these toilets?
Convenience: This kind of bathroom makes it no longer embarrassing for parents to take their children to the bathroom
Yesterday, in a large shopping mall on Kaixuan Road, the citizen Ms. Mao took her son into a special bathroom: its door did not have the common words "male" or "female", instead it was replaced by a striking parent-child icon ( As shown in the picture), when entering the bathroom, there is an icon with the words "Mommy & Baby" on the wall on the left hand side, and the icon "Daddy & Baby" on the right hand side.
Ms. Mao took the child to turn left and solved the "convenience" problem in one of the cubicles. It was not the first time that she brought her son to this bathroom. In Ms. Wang's view, such partitions provide a lot of convenience for fathers and mothers who take their children alone, "and there are also children's toilets, which are simply too practical."
From a functional point of view, the toilet that Ms. Wang uses with her son is the "third toilet."
Question: These toilets have special functions, but they have been left out
The reporter visited and found that many public toilets have set up facilities similar to the "third toilet" around us. In most cases, they are shown as "barrier-free facilities": an icon with a wheelchair is posted at the door. Safety handrails, railings, etc. are installed beside toilets and sinks.
In a public toilet on Dingding North Road, the reporter found a "third toilet" with relatively more facilities, which not only has common barrier-free facilities, but also a crib that can change diapers for babies. However, the reporter was in the public toilet. After observing for a long time, I didn't see anyone using this bathroom. Asked why, many citizens said that they thought this was a toilet for disabled people only.
According to the relevant person in charge of the Municipal Environmental Sanitation Department, there are 657 urban public toilets in the urban area of the city. Among them, the urban public toilets located near some scenic spots have the dual functions of urban public toilets and tourist public toilets, so barrier-free toilets or maternity and infant toilets with the function of “third toilet” were installed during construction. However, due to the recognition of the citizens Degree and management reasons, some of them did not fully perform their original functions.
Suggestion: I hope it can be extended to more places in the future
During the interview, many citizens put forward their views on the novelty of the "third bathroom".
Mr. Zhou, who lives in Jianxi District, believes that the "third bathroom" should not only have a scenic spot, but it should also be promoted to the whole society; college student Xiao Wu suggested that the "third bathroom" can be added with some detailed instructions at the door to let everyone understand it. The specific function is because many people may be embarrassed when they enter the door suddenly; Ms. Song, who has retired, feels that the hospital should also set up some separate "third toilets" so that when she goes to the hospital to take care of her spouse and children, she will be embarrassed. Don't worry about helping him to the toilet anymore.
The reporter learned from the Municipal Environmental Sanitation Department that although the "third toilet" is not compulsorily included in the urban public toilet construction standards, the city encourages public places with conditions to install more convenient public toilet facilities. In the future, as the urban infrastructure continues to improve , Around us, there may be more fully functional "third toilets".
Source: Luoyang Evening News (Reporter Wisdom Text/Picture)
Related Links
"Third toilet", also known as family toilet in the world, refers to a toilet specially set up for people with behavioral disabilities or relatives (especially the opposite sex) who cannot take care of themselves. It is used to solve the inconvenience of toileting for some special objects. Problems, such as daughters assisting old fathers, sons assisting old mothers, mothers assisting little boys, fathers assisting little girls, etc.
Although the linear shower drain is taken into account a comparatively new product, it's a sensible answer for toilet voidance. This linear shower drain permits a bespoke answer that provides the toilet with a contemporary and distinctive look and elegance. What's linear shower voidance and what voidance blessings will it offer?
Here is the content list:
Excellent style and sensible materials
Low issue of installation several choices offered
Shower drains operate well
This linear shower drains square measure is the most effective style selection for shower voidance. They disagree with alternative contoured shower drains by the presence of inlets within the type of drains with a length of thirty-five to one hundred fifty cm. once putting in linear shower drains. The slope is created on one facet solely, that appearance is esthetically pleasing and doesn't need beveled tile cuts, which can additionally cut back labor prices. once selecting a linear shower drain. Attention must be paid to the fabric from that it's created, as result of plastic models with sharp changes in close temperature will expand and alter their pure mathematics, which can impair their more operate, and we have these units during a variation of chrome steel.
Linear shower drains have an extended, slim "line" form and may thus be put in unidirectional shower stalls. The principle of those drains relies on permitting water to flow through the drain into a channel underneath the ground and the regular system. One in every of their biggest blessings is that linear shower drains may be put in any place, at the brink, on the wall or underneath the booth if you want. Additionally, our linear shower drains have a sleek, clean look and are available in several style choices. They're particularly helpful for doorless shower styles. If you favor a seamless restroom floor, you'll select a drain tile with tile that matches your floor precisely and therefore the linear shower drain is nearly invisible.
Many people square measure hesitant to shop for linear shower drains, as a result, they do not recognize abundant maintenance and that they suppose they're too sophisticated to put. One of every of the largest queries is whether or not or not linear voidance can drain smoothly. The solution is not a retardant. The planning relies on a high flow and you'll make certain that your restroom won't be flooded. Maintenance is not any different from that of alternative voidance systems, and with a contemporary shower basin, the voidance in your restroom is certain to be in good condition. The grid of linear shower drains will simply be affected if required, which helps with cleansing.
DIKALAN is specially engaged in services like taps, shower elements, floor drains, and international trade. Committed to providing customers with high-quality, high-efficiency products and solutions for patrons. Our industrial plant was established in 1998. With twenty-five years of production expertise and quite two hundred staff, the corporate has a robust production force and R&D capabilities.
